Product Name：TMZA type chemical process pump
Product model:
Product note:
Browse：

Introduction：

TMZA type oil chemical process pump is a single-stage horizontal centrifugal pump, is our company according to the American Petroleum Institute API610 standard and VDMA24297 (light / medium) specification design and manufacture of pump products, and in the original ZA type pump based on the optimization and improvement, and effectively improve the product reliability: this type of pump body for the standard in the OH1 type structure, the basic structure is closed structure, according to the characteristics of the transmission medium can also be designed as open or fully open structure: axial suction, radial discharge. According to the working condition, the hydraulic balance of the front and back wear ring and the balance hole is carried out. Seal with packing seal, single end sealing or double sealing machine, and set the cooling circulation system, flushing or sealing liquid.

Standard pipe according to the API610 specification design, suction and discharge pipe flange pressure rating.

Pump work shift: from the drive motor end, the pump is turned to a clockwise rotation.
